The STIHL HTA 160 battery pole pruner efficiently supports professionals in tree care, orchards, local authorities and agriculture and forestry when pruning trees, removing dead wood and breakage caused by storms, and pruning fruit trees.
The powerful EC motor of the STIHL HTA 160 is powered by lithium-ion batteries from the STIHL AP System. The lightweight, robust magnesium transmission supports easy manoeuvring. You can use the pole pruner to cut branches and trees up to 20 cm in diameter. Thanks to the professional telescopic shaft with a particularly rigid square profile, the desired overall length of the HTA 160 can be easily adjusted up to 405 cm with quick adjustment. This enables exact positioning and precise cutting even in higher areas of trees. You can even work up to a height of around 5 m for thinning out treetops. The HTA 160 is fitted with the 1/4" P Picco Micro 3 (PM3) saw chain. No ear protection is required with 1/4" STIHL saw chains, so you can also work in noise-sensitive areas.
A robust branch hook cast onto the compact cutting head makes it easier to grasp and remove loose cuttings. The sprocket cover is equipped with a direction guide for precise positioning and lateral chip ejection. Thanks to the ergonomically optimised control handle with LED display, you have all the controls of the STIHL HTA 160 conveniently at hand. The standard STIHL protective foot protects the motor housing of the pole pruner from contact with the ground. The easy-to-clean air filter with metal mesh supports optimal motor cooling and as such a long service life for your STIHL HTA 160. The optionally available STIHL RTS harness allows you to take the strain off your back while maintaining a high level of freedom of movement for longer periods of work.
The STIHL HTA 160 has a total length of 285 cm to 405 cm.
All battery power tools within the STIHL AP system have been designed for professional users and daily work, even in adverse weather conditions. With that in mind they are certified as splashproof. The effectiveness of this is also verified through demanding internal tests. The splashwater test is aligned with the IPX4 standard, among others.
Our overview of STIHL battery life and charging times shows how long you can work with your STIHL HTA 160 battery pole pruner and how long the battery used takes to charge.
- Battery life with AP 200 / S battery: Up to 22 min
- Battery life with recommended AP 300 S battery: Up to 45 min
- Battery life with AP 500 S battery: Up to 54 min
- Battery life with AR 2000 L battery: Up to 160 min
For optimal use, please refer to our battery compatibility overview.
Technical details
| Rated voltage |
36 V |
| Power consumption |
1.85 kW |
| Power |
1.40 kW 1)
|
| Cordless power system |
AP |
| Recommended battery |
AP 300 S |
| Device weight without battery |
6.9 kg 2)
|
| Bar length |
30 cm 3)
|
| Bar length |
12 in 3)
|
| Groove width |
1.10 mm |
| Saw chain pitch |
1/4"P |
| IPX Rating |
IPX4 |
| Max. battery working time AP 100 |
18 min 4)
|
| Max. battery working time AP 200 |
36 min 4)
|
| Max. battery working time AP 200 S |
36 min 4)
|
| Max. battery working time AP 300 |
56 min 4)
|
| Max. battery working time AP 300 S |
70 min 4)
|
| Max. battery working time AP 500 S |
80 min 4)
|
| Max. battery working time AR 2000 L |
262 min 4)
|
| Max. battery working time AR 3000 L |
393 min 4)
|
| Min. device length with tool |
285 cm |
| Max. device length with tool |
405 cm |
| Sound pressure level |
85 dB(A) 5)
|
| Sound power level |
97 dB(A) 5)
|
| Vibration level, left |
4.3 m/s² 6)
|
| Vibration level, right |
5.1 m/s² 6)
|
